Rogers Engineered Liquid Ring Compression System (RCS.LR)

The technology of the liquid ring compressor is well suited for process gas streams which include condensable vapors and particulates.

Single and two-stage designs for many combinations of flow and discharge pressure to suit many applications.

The seal fluid that forms the liquid ring is commonly water, but does not have to be, as it can be any kind of process compatible fluid. Seal fluid can be separated, filtered/cleaned/treated, cooled and recirculated back to the pump's inlet if desired.

Many different selections for materials of construction (cast iron, stainless steel, specialty metals, combination) and sealing (mechanical seals or packing).

Translation missing: en.Designed & Manufactured in the USA

Need help? Call us: 1 503 639 0808

Product details

Compression Technology	Volumetric Flow	Discharge Pressure	Features
Oil-free (if oil is not seal fluid)	Up to 6800 ACFM (~10,500 m3/hr)	Up to ~170 PSIG	Once through and recirculating options Cast iron, carbon steel, stainless steel, or specialty metal construction available Fixed speed or VFD Direct or belt drive

Description

The liquid ring compression technology is ideal for a variety of industries, including:

Specifications

Compression Technology	Volumetric Flow	Discharge Pressure	Features
Oil-free (if oil is not seal fluid)	Up to 6800 ACFM (~10,500 m3/hr)	Up to ~170 PSIG	Once through and recirculating options Cast iron, carbon steel, stainless steel, or specialty metal construction available Fixed speed or VFD Direct or belt drive
