MD-Kinney Vacuum Pumps, Parts & Repair l AK, MT, OR, WA, ID

MD-Kinney distributor Rogers Machinery offers MD-Kinney Vacuum Pumps as well as MD-Kinney pump parts & service for the northwest region. We provide knowledgeable selection assistance with MD-Kinney vacuum pumps in Alaska, Montana, Oregon, Washington, and Idaho.

MD-Kinney is a leading manufacturer of high performance, reliable positive displacement blowers, mechanical vacuum pumps, vacuum boosters, and engineered vacuum pump systems. Since combining in 2002, the M-D Pneumatics and Kinney brands have continued their 100+ year history of providing long-lasting quality products for industrial markets.

MD-Kinney Vacuum Pumps Line Overview

Rogers Machinery offers MD-Kinney’s complete line of rugged and reliable industrial vacuum pumps, including liquid ring vacuum pumps, rotary vane vacuum pumps, dry claw vacuum pumps, rotary piston pumps, vacuum booster pumps, and oil free screw vacuum pumps. As an authorized MD-Kinney distributor, Rogers Machinery stocks a variety of MD-Kinney vacuum pumps, and we can help select and size the right MD-Kinney vacuum pump for your needs.

Rotary Vane Vacuum Pump

The simple, compact design of MD-Kinney’s rotary vane vacuum pumps ensure reliability and durability.

MD-Kinney Rotary Vane Pumps feature:

Capacity ranges from 7-903 CFM
Motor: 0.75-40 HP
Most models can achieve ultimate pressure levels near 0.1 mbar and ultimate vacuum levels near 0.075 Torr (0.375 Torr with gas ballast in operation).
Continuous operation
Worry-free maintenance
Easy installation
Optimized performance
Easy maintenance with only two moving parts

Dry Claw Vacuum Pump

Dry claw vacuum pumps are a type of dry vacuum pump offering contactless and oil-free dry compression. Claw-shaped rotors are designed to operate efficiently without contact and without the need for a sealing fluid.

MD-Kinney’s KVC Claw series serves a variety of applications where high-volume air is required:

3-15 HP
Up to 27 in. HgV (75 Torr) for continuous operation
Capacity ranges from 43 to 671 CFM

Dry Screw Vacuum Pump

MD-Kinney dry screw pumps are designed to be reliable, dependable, and environmentally friendly for even the toughest industrial and process applications.

MD-Kinney dry screw vacuum pump series include:

Available in capacity ranges from 71 - 459 ACFM
Motore: 5-30 HP
Ultimate pressure between 0.01-0.05 Torr (0.013 mbar)
KDP Series: designed to handle process by-products such as liquids, condensate, and small particles
SDV Series: Space saving C-face motor design with Niflon coated internals to reduce damage from corrosive or condensate gases

Rotary Piston Pump

MD-Kinney Rotary Piston Pumps are known for durability in harsh applications including especially dirty processes. These rugged, reliable pumps are capable of high pumping capacity at low pressure.

Available in capacity ranges from 5-778 ACFM
Motor: 5-778 HP
Ultimate pressure down to 0.1 Torr (0.13 mnar)
No internal metal to metal contact
Clearances filled with oil
Duplex or triplex piston design
Air-cooled or water-cooled

Liquid Ring Vacuum Pump

MD-Kinney liquid ring vacuum pumps feature rugged construction for increased reliability, efficiency, and dependability in severe industrial applications. Options include the single-stage A Series and the two-stage KLRC that serve applications from 5 to 900 CFM, 4 Torr (5.3 mbar a).

A-Series pumps feature a unique axial flow design for the most severe of industrial conditions.

Capacity ranges from 15 - 235 ACFM
Ultimate vacuum pressure down to 25 Torr (33 mbar a)
Motor: 1-20 HP
Can operate flooded without damage
Can run 24/7 operations for years with no maintenance
Single-stage

The KLRC liquid ring vacuum pump series is ideal for pumping wet mixtures, even slugs of liquid.

Capacity ranges from 77 to 900 CFM
Ultimate vacuum pressure levels near 4 Torr (5.3 mbar a)
Motor: 5 - 100 HP
Two-stage

Vacuum Booster Pump

MD-Kinney vacuum boosters are designed for use with all types of vacuum pumps to increase pumping speed, reduce cost, increase flow, and improve energy efficiency.

MD-Kinney vacuum booster pumps are positive displacement dry pumps that increase cfm and achieve deeper vacuum. Two-lobe rotors spin in opposite directions to remove gas and create faster pumping speeds. When placed in series with another vacuum pump, higher pumping capacity and lower pressures can be achieved typically at lower cost and power consumption.

The backing pump can be an oil-sealed piston or vane pump, a liquid ring pump or a dry vacuum pump.

Standard features:

Capacitiy ranges from 150 to 10000 CFM
Cast iron housing, end plates, and port fitting
Ductile iron rotors and shafts

Standard construction materials:

Stainless steel
Carbon steel
Ductile iron
Bi-Protec

MD-Kinney Industrial Vacuum Pump Products

MD-Kinney Vacuum Pump Parts and Vacuum Pump Lubricants

Rogers Machinery maintains an inventory of genuine MD-Kinney vacuum pump parts and accessories for regular maintenance and repair needs. We have multiple locations throughout the Northwest offering MD-Kinney vacuum pump parts and service.

Request Parts or Lubricants

MD-Kinney Vacuum Pump Repair Service

Rogers Machinery offers MD-Kinney vacuum pump repair service for the regular maintenance, installation, and on-site repair of your MD-Kinney industrial vacuum pumps. Our highly qualified technicians are factory trained to assess service needs, complete repairs, and make sure your pump performs to factory specifications. We use genuine OEM MD-Kinney vacuum pump parts to keep your pumps operating at peak efficiency. Contact Rogers Machinery for your next MD-Kinney vacuum pump repair service.

Request Service
