Viking Pump - SEP Series Cryogenic Cold Weather Pumps
Viking Pump’s stainless steel 4197-SEP Series™ cryogenic pumps are made for the cold! With a low-temperature rating of -70°C, these pumps are made to meet the pressures and temperatures of your cold ethanol extraction needs.
- Capacity 10 – 75GPM
- Viscosity 28-500 SSU
- Pressure to 200PSI
- Temperature to -95F to 225F
-
This product price is available on request only
Product details
4197 Series™ and 4197-SEP Series™ pumps are designed for foot type horizontal mounting. These pumps are built for continuous or intermittent duty for such applications as filtering, circulating, transferring or booster service in general industrial, petrochemical, and other industries. The 4197-SEP Series™ pumps are specially fit with low temperature materials suitable for subzero solvent transfer or circulation applications. They are also assembled and tested using only food grade liquids.
-
- Superior self-priming capabilities
- Low temperature mechanical seal
- Quiet pulsation-free flow
- Designed for continuous or intermittent duty cycle
- Assembled and tested with food grade liquids
- Reliable, steady flow regardless of changes in pressure or viscosity
- Electric motor driven and VFD compatible
Sealed anti-friction bearings eliminate the need for relubrication
Threaded one-piece bearing housing allows for end clearance adjustment
Behind the rotor seal, so shaft and bearings not exposed to process fluid
One-piece casing ensures alignment for maximum bearing and seal life
ANSI flanges easily convert to tri-clamp
ISO 9001:2015 Certified
-
Standard 150 Flanged Ports Nominal Flow (60 Hz) Max Differential Pressure Temperature Range Shipping Weight Model Port Size GPM RPM PSIG oF oC Lbs GG4197-SEP1 1" 10 1750 200 -95 to +225 -70 to +105 20 HJ4197-SEP1 1.5" 20 1750 200 -95 to +225 -70 to +105 50 HL4197-SEP1 1.5" 30 1750 200 -95 to +225 -70 to +105 50 AS4197-SEP1 3" 35 1150 200 -95 to +225 -70 to +105 115 AK4197-SEP1 3" 50 1150 200 -95 to +225 -70 to +105 115 AL4197-SEP1 3" 75 1150 200 -95 to +225 -70 to +105 120 Note: Please contact Viking Pump for performance curves specific to your application.
-
- Description
- Superior self-priming capabilities
- Low temperature mechanical seal
- Quiet pulsation-free flow
- Designed for continuous or intermittent duty cycle
- Assembled and tested with food grade liquids
- Reliable, steady flow regardless of changes in pressure or viscosity
- Electric motor driven and VFD compatible
Sealed anti-friction bearings eliminate the need for relubrication
Threaded one-piece bearing housing allows for end clearance adjustment
Behind the rotor seal, so shaft and bearings not exposed to process fluid
One-piece casing ensures alignment for maximum bearing and seal life
ANSI flanges easily convert to tri-clamp
ISO 9001:2015 Certified
- Specifications
Standard 150 Flanged Ports Nominal Flow (60 Hz) Max Differential Pressure Temperature Range Shipping Weight Model Port Size GPM RPM PSIG oF oC Lbs GG4197-SEP1 1" 10 1750 200 -95 to +225 -70 to +105 20 HJ4197-SEP1 1.5" 20 1750 200 -95 to +225 -70 to +105 50 HL4197-SEP1 1.5" 30 1750 200 -95 to +225 -70 to +105 50 AS4197-SEP1 3" 35 1150 200 -95 to +225 -70 to +105 115 AK4197-SEP1 3" 50 1150 200 -95 to +225 -70 to +105 115 AL4197-SEP1 3" 75 1150 200 -95 to +225 -70 to +105 120 Note: Please contact Viking Pump for performance curves specific to your application.
